Applicable scope
1. 1 division, 2 division Ⅱ A ~ Ⅱ C explosive gases, and/or 20 area,Zone 21, 22 area in which combustible dust place;
2. Temperature classes: T1 ~ T6;
3. Indoor, outdoor (IP65, IP66 * when ordering need to put forward);
4. Used in the chemical, oil, oil, Marine oil platform, tankers, armywork and other dangerous places.
Model implication
Main technical parameters
| Rated voltage(V) | Rated current(A) | Ex-mark | Erosion-proof class | Degree of protection | Inlet thread(G) | Cable outer dia.(mm) |
| AC: 24/36/110/127/220/380 | 5 | ExdⅡCT6Gb/ DIPA20TA,T6 | F1, WF1 | IP66 | 1/2 | φ8～φ10 |
| DC: 12/24/36/110/220 |
| Type | Contact terminal quantity(in pair) | Operating travel | Overtravel | Operating force(N) | |
| Open | Close | ||||
| dLXK-15Z(L)C | 1 | 1 | 1～3mm | 2mm | ≤19.6 |
| dLXK-15BC | 12～15° | ≥30° | ≤9.8 | ||
| dLXK-15HC | ≥45° | ≥30° | ≤14.7 | ||
| dLXK-15NC | 1～3mm | 2mm | ≤19.6 | ||
Appearance and installation size
